二、技术参数：
型号 | 额定电流比（KV） | 额定二次输出(VA) | 穿心匝数 | ||
0.5级 | 0.5S级 | 0.2S级 | |||
LMZ(J)1-0.66/30 | 100/5 | 5 | / | / | 1 |
150/5 | 5 | 5 | 5 | 1 | |
200/5 | 5 | 5 | 5 | 1 | |
250/5 | 5 | 5 | 5 | 1 | |
300/5 | 5 | 5 | 5 | 1 | |
LMZ(J)1-0.66/40 | 150/5 | 5 | / | / | 1 |
200/5 | 5 | / | / | 1 | |
250/5 | 5 | / | / | 1 | |
300/5 | 5 | / | / | 1 | |
400/5 | 5 | / | / | 1 | |
LMZ(J)1-0.66/50 | 400/5 | 5 | 5 | 5 | 1 |
500/5 | 5 | 5 | 5 | 1 | |
600/5 | 5 | 5 | 5 | 1 | |
LMZ(J)1-0.66/60 | 400/5 | 5 | / | / | 1 |
500/5 | 5 | / | / | 1 | |
600/5 | 5 | 5 | 5 | 1 | |
750/5 | 10 | 5 | 5 | 1 | |
800/5 | 10 | 5 | 5 | 1 | |
1000/5 | 10 | 5 | 5 | 1 | |
LMZ(J)1-0.66/80 | 600/5 | 10 | 5 | 5 | 1 |
750/5 | 10 | 10 | 10 | 1 | |
800/5 | 10 | 10 | 10 | 1 | |
1000/5 | 10 | 10 | 10 | 1 | |
1200/5 | 10 | 10 | 10 | 1 | |
1500/5 | 10 | 10 | 10 | 1 | |
LMZ(J)1-0.66/100 | 750/5 | 10 | 10 | 10 | 1 |
800/5 | 10 | 10 | 10 | 1 | |
1000/5 | 10 | 10 | 10 | 1 | |
1200/5 | 10 | 10 | 10 | 1 | |
1500/5 | 10 | 10 | 10 | 1 | |
.2000/5 | 20 | 20 | 20 | 1 | |
LMZ(J)1-0.66/130 | 1500/5 | 10 | 10 | 10 | 1 |
.2000/5 | 20 | 20 | 20 | 1 | |
.2500/5 | 20 | 20 | 20 | 1 | |
3000/5. | 20 | 20 | 20 | 1 | |
LMZ(J)1-0.66/170 | 3000/5. | 20 | 20 | 20 | 1 |
4000/5. | 40 | 40 | 40 | 1 | |
5000/5. | 40 | 40 | 40 | 1 | |
6000/5. | 40 | 40 | 40 | 1 | |
