二、技术参数表：
型号 | 额定电流比（KV） | 额定二次输出(VA) | 穿心匝数 | ||||
1级 | 0.5级 | 0.5S级 | 0.2级 | 0.2S级 | |||
SDH-0.66II | 5/5 | 10 | 5 | 5 | 5 | 5 | / |
10/5 | 10 | 5 | 5 | 5 | 5 | / | |
15/5 | 10 | 5 | 5 | 5 | 5 | / | |
20/5 | 10 | 5 | 5 | 5 | 5 | / | |
30/5 | 10 | 5 | 5 | 5 | 5 | / | |
40/5 | 10 | 5 | 5 | 5 | 5 | / | |
50/5 | 10 | 5 | 5 | 5 | 5 | / | |
75/5 | 10 | 5 | 5 | 5 | 5 | / | |
100/5 | 10 | 5 | 5 | 5 | 5 | / | |
SDH-0.66/40II | 150/5 | 5 | 2.5 | / | / | / | / |
200/5 | 5 | 5 | / | / | / | 1 | |
250/5 | 5 | 5 | / | / | / | 1 | |
300/5 | 5 | 5 | / | / | / | 1 | |
400/5 | 5 | 5 | / | / | / | 1 | |
500/5 | 10 | 10 | 5 | 5 | 5 | 1 | |
600/5 | 10 | 10 | 5 | 5 | 5 | 1 | |
750/5 | 10 | 10 | 10 | 10 | 10 | 1 | |
150/1 | 5 | 5 | / | / | / | 1 | |
200/1 | 5 | 5 | / | / | / | 1 | |
250/1 | 5 | 5 | / | / | / | 1 | |
300/1 | 5 | 5 | / | / | / | 1 | |
400/1 | 5 | 5 | / | / | / | 1 | |
500/1 | 10 | / | / | / | / | 1 | |
600/1 | 10 | / | / | / | / | 1 | |
SDH-0.66/50II | 150/5 | 2.5 | 5 | / | / | / | 1 |
200/5 | 5 | 5 | / | / | / | 1 | |
250/5 | 5 | 5 | / | / | / | 1 | |
300/5 | 5 | 5 | / | / | / | 1 | |
400/5 | 5 | 10 | / | / | / | 1 | |
500/5 | 10 | 10 | 5 | 5 | 5 | 1 | |
600/5 | 10 | 10 | 5 | 5 | 5 | 1 | |
750/5 | 10 | 10 | 10 | 10 | 5 | 1 | |
800/5 | 10 | 10 | 10 | 10 | 5 | 1 | |
1000/5 | 10 | 10 | 10 | 10 | 5 | 1 | |
1200/5 | 20 | 20 | 20 | 20 | 5 | 1 | |
150/1 | 2.5 | 1 | / | / | / | 1 | |
200/1 | 5 | 2.5 | / | / | / | 1 | |
250/1 | 5 | 2.5 | / | / | / | 1 | |
300/1 | 5 | 5 | / | / | / | 1 | |
400/1 | 5 | 5 | / | / | / | 1 | |
500/1 | 10 | 10 | / | 5 | / | 1 | |
600/1 | 10 | 10 | / | 5 | / | 1 | |
750/1 | 10 | 10 | / | 10 | / | 1 | |
800/1 | 10 | 10 | / | 10 | / | 1 | |
1000/1 | 10 | 10 | / | 10 | / | 1 | |
SDH-0.66/60II | 200/5 | 5 | 5 | / | / | 5 | 1 |
250/5 | 5 | 5 | / | / | 5 | 1 | |
300/5 | 5 | 5 | / | / | 5 | 1 | |
400/5 | 5 | 5 | / | / | 5 | 1 | |
500/5 | 10 | 10 | / | / | 5 | 1 | |
600/5 | 10 | 10 | 5 | 5 | 5 | 1 | |
750/5 | 10 | 10 | 5 | 5 | 5 | 1 | |
800/5 | 10 | 10 | 10 | 10 | 5 | 1 | |
1000/5 | 10 | 10 | 10 | 10 | 5 | 1 | |
1200/5 | 20 | 20 | 10 | 10 | 5 | 1 | |
1500/5 | 20 | 20 | 20 | 20 | 5 | 1 | |
200/1 | 5 | 5 | 20 | 20 | 10 | 1 | |
250/1 | 5 | 5 | / | / | / | 1 | |
300/1 | 5 | 5 | / | / | / | 1 | |
400/1 | 5 | 5 | / | / | / | 1 | |
500/1 | 10 | 10 | / | / | / | 1 | |
600/1 | 10 | 10 | / | / | / | 1 | |
750/1 | 10 | 10 | / | 10 | / | 1 | |
800/1 | 10 | 10 | / | 10 | / | 1 | |
1000/1 | 10 | 10 | / | 10 | / | 1 | |
1200/1 | 20 | 20 | / | 20 | / | 1 | |
SDH-0.66/80II | 600/5 | 10 | 10 | / | / | / | 1 |
750/5 | 10 | 10 | / | 10 | / | 1 | |
800/5 | 10 | 10 | 10 | 10 | 5 | 1 | |
1000/5 | 10 | 10 | 10 | 20 | 5 | 1 | |
1200/5 | 20 | 20 | 20 | 20 | 5 | 1 | |
1500/5 | 20 | 20 | 20 | 20 | 10 | 1 | |
2000/5 | 20 | 20 | 20 | 10 | 10 | 1 | |
600/1 | 10 | 10 | / | / | / | 1 | |
750/1 | 10 | 10 | / | 10 | / | 1 | |
800/1 | 10 | 10 | / | 10 | / | 1 | |
1000/1 | 10 | 10 | / | 10 | / | 1 | |
1200/1 | 20 | 20 | / | 20 | / | 1 | |
1500/1 | 20 | 20 | / | 20 | / | 1 | |
SDH-0.66/100II | 1000/5 | 10 | 10 | 10 | 10 | 5 | 1 |
1200/5 | 20 | 20 | 20 | 20 | 5 | 1 | |
1500/5 | 20 | 20 | 20 | 20 | 10 | 1 | |
2000/5 | 20 | 20 | 20 | 20 | 10 | 1 | |
2500/5 | 40 | 40 | 40 | 40 | 10 | 1 | |
1000/1 | 10 | 10 | / | 10 | / | 1 | |
1200/1 | 20 | 20 | / | 20 | / | 1 | |
1500/1 | 20 | 20 | / | 20 | / | 1 | |
2000/1 | 20 | 20 | / | 20 | / | 1 | |
SDH-0.66/120II | 1000/5 | 10 | 10 | 10 | 10 | 5 | 1 |
1200/5 | 20 | 20 | 20 | 20 | 10 | 1 | |
1500/5 | 20 | 20 | 20 | 20 | 10 | 1 | |
2000/5 | 20 | 20 | 20 | 20 | 10 | 1 | |
2500/5 | 40 | 40 | 40 | 40 | 10 | 1 | |
3000/5 | 40 | 40 | 40 | 40 | 10 | 1 | |
4000/5 | 40 | 40 | 40 | 40 | 10 | 1 | |
1000/1 | 10 | 10 | / | 10 | / | 1 | |
1200/1 | 20 | 20 | / | 20 | / | 1 | |
1500/1 | 20 | 20 | / | 20 | / | 1 | |
2000/1 | 20 | 20 | / | 20 | / | 1 | |
2500/1 | 40 | 40 | / | 40 | / | 1 | |
3000/1 | 40 | 40 | / | 40 | / | 1 | |
SDH-0.66/125III | 2000/5 | 20 | 20 | 20 | 20 | 10 | 1 |
2500/5 | 40 | 40 | 40 | 40 | 10 | 1 | |
3000/5 | 40 | 40 | 40 | 40 | 10 | 1 | |
4000/5 | 40 | 40 | 40 | 40 | 10 | 1 | |
5000/5 | 40 | 40 | 40 | 40 | 10 | 1 | |
2000/1 | 20 | 20 | / | 20 | / | 1 | |
2500/1 | 40 | 40 | / | 40 | / | 1 | |
3000/1 | 40 | 40 | / | 40 | / | 1 | |
4000/1 | 40 | 40 | / | 40 | / | 1 | |
5000/1 | 40 | 40 | / | 40 | / | 1 | |
SDH-0.66/150III | 3000/5 | 40 | 40 | 40 | 40 | 10 | 1 |
4000/5 | 40 | 40 | 40 | 40 | 10 | 1 | |
5000/5 | 40 | 40 | 40 | 40 | 10 | 1 | |
3000/1 | 40 | 40 | / | 40 | / | 1 | |
4000/1 | 40 | 40 | / | 40 | / | 1 | |
5000/1 | 40 | 40 | / | 40 | / | 1 | |
SDH-0.66/165III | 4000/5 | 40 | 40 | 40 | 40 | 10 | 1 |
5000/5 | 40 | 40 | 40 | 40 | 10 | 1 | |
6000/5 | 40 | 40 | 40 | 40 | 10 | 1 | |
4000/1 | 40 | 40 | / | 40 | / | 1 | |
5000/1 | 40 | 40 | / | 40 | / | 1 | |
6000/1 | 40 | 40 | / | 40 | / | 1 | |
