型号 | 额定电流比（KV） | 额定二次输出(VA) | 穿心匝数 | |||
1级 | 0.5级 | 0.5S级 | 0.2级 | |||
BH-0.66I(实心) | 5/5 | 5 | 2.5 | / | / | / |
10/5 | 5 | 2.5 | / | / | / | |
15/5 | 5 | 2.5 | / | / | / | |
20/5 | 5 | 2.5 | / | / | / | |
25/5 | 5 | 2.5 | / | / | / | |
30/5 | 5 | 2.5 | / | / | / | |
40/5 | 5 | 2.5 | / | / | / | |
50/5 | 5 | 2.5 | / | / | / | |
75/5 | 5 | 2.5 | / | / | 5 | |
BH-0.66 30I | 30/5 | 5 | 2.5 | / | / | 3 |
50/5 | 5 | 2.5 | / | / | 2 | |
75/5 | 5 | 2.5 | / | / | 1 | |
75/5 | 2.5 | / | / | / | 1 | |
100/5 | 2.5 | / | / | / | 2 | |
100/5 | 5 | 5 | / | / | 1 | |
150/5 | 5 | 2.5 | / | / | 1 | |
200/5 | 5 | 5 | / | / | 1 | |
250/5 | 5 | 5 | / | / | 1 | |
300/5 | 5 | 5 | / | / | 1 | |
400/5 | 5 | 5 | / | / | 1 | |
BH-0.66 30IB | 30/5 | / | / | 2.5 | 2.5 | 5 |
50/5 | / | / | 2.5 | 2.5 | 3 | |
75/5 | / | / | 2.5 | 2.5 | 2 | |
75/5 | 5 | 2.5 | / | / | 1 | |
100/5 | 5 | 2.5 | / | / | 1 | |
100/5 | / | / | 5 | 5 | 2 | |
150/5 | / | / | 2.5 | 2.5 | 1 | |
200/5 | / | / | 5 | 5 | 1 | |
250/5 | / | / | 5 | 5 | 1 | |
300/5 | / | / | 5 | 5 | 1 | |
BH-0.66 40I | 30/5 | 5 | 2.5 | / | / | 5 |
50/5 | 5 | 2.5 | / | / | 3 | |
75/5 | 5 | 2.5 | / | / | 2 | |
75/5 | 2.5 | / | / | / | 1 | |
100/5 | 2.5 | / | / | / | 1 | |
100/5 | 5 | 5 | / | / | 2 | |
150/5 | 5 | 2.5 | / | / | 1 | |
200/5 | 5 | 5 | / | / | 1 | |
250/5 | 5 | 5 | / | / | 1 | |
300/5 | 5 | 5 | / | / | 1 | |
400/5 | 5 | 5 | / | / | 1 | |
500/5 | 10 | 10 | 5 | 5 | 1 | |
600/5 | 10 | 10 | 5 | 5 | 1 | |
BH-0.66 50I | 150/5 | 2.5 | / | / | / | 1 |
200/5 | 5 | 2.5 | / | / | 1 | |
250/5 | 5 | 5 | / | / | 1 | |
300/5 | 5 | 5 | / | / | 1 | |
400/5 | 5 | 10 | / | / | 1 | |
500/5 | 10 | 10 | 5 | 5 | 1 | |
600/5 | 10 | 10 | 5 | 5 | 1 | |
750/5 | 10 | 10 | 10 | 10 | 1 | |
800/5 | 10 | 10 | 10 | 10 | 1 | |
1000/5 | 10 | 10 | 10 | 10 | 1 | |
1200/5 | 20 | 20 | 20 | 20 | 1 | |
BH-0.66 60I | 200/5 | 5 | / | / | / | 1 |
250/5 | 5 | 5 | / | / | 1 | |
300/5 | 5 | 5 | / | / | 1 | |
400/5 | 5 | 5 | / | / | 1 | |
500/5 | 10 | 10 | 5 | 5 | 1 | |
600/5 | 10 | 10 | 5 | 5 | 1 | |
750/5 | 10 | 10 | 10 | 10 | 1 | |
800/5 | 10 | 10 | 10 | 10 | 1 | |
1000/5 | 10 | 10 | 10 | 10 | 1 | |
1200/5 | 20 | 20 | 20 | 20 | 1 | |
1500/5 | 20 | 20 | 20 | 20 | 1 | |
BH-0.66 80I | 300/5 | 5 | 5 | / | / | 1 |
400/5 | 5 | 5 | / | / | 1 | |
500/5 | 10 | 10 | / | / | 1 | |
600/5 | 10 | 10 | / | / | 1 | |
750/5 | 10 | 10 | 10 | 10 | 1 | |
800/5 | 10 | 10 | 10 | 10 | 1 | |
1000/5 | 10 | 20 | 10 | 10 | 1 | |
1200/5 | 20 | 20 | 20 | 20 | 1 | |
1500/5 | 20 | 20 | 20 | 20 | 1 | |
2000/5 | 20 | 20 | 20 | 20 | 1 | |
BH-0.66 100I | 600/5 | 10 | 10 | / | / | 1 |
750/5 | 10 | 10 | 10 | 10 | 1 | |
800/5 | 10 | 10 | 10 | 10 | 1 | |
1000/5 | 10 | 10 | 10 | 10 | 1 | |
1200/5 | 20 | 20 | 20 | 20 | 1 | |
1500/5 | 20 | 20 | 20 | 20 | 1 | |
2000/5 | 20 | 20 | 20 | 20 | 1 | |
2500/5 | 40 | 40 | 40 | 40 | 1 | |
BH-0.66 120I | 1000/5 | 10 | 10 | 10 | 10 | 1 |
1200/5 | 20 | 20 | 20 | 20 | 1 | |
1500/5 | 20 | 20 | 20 | 20 | 1 | |
2000/5 | 20 | 20 | 20 | 20 | 1 | |
2500/5 | 40 | 40 | 40 | 40 | 1 | |
3000/5 | 40 | 40 | 40 | 40 | 1 | |
4000/5 | 40 | 40 | 40 | 40 | 1 | |
